GPR survey used to locate voiding caused by steam pipe rupture at an Adelaide power station
3D mapping of Post Tension Cables
Large GPR wall survey 7.2 metres x 1.2 metres for void detection at the Adelaide desalination plant
GPR leak detection survey at Murray Bridge water filtration plant.
Looking for voiding (honeycomb effect) in new walls at Honeymoon uranium mine
3D mapping of reinforcing mat at SAHMRI site Adelaide
UPV pile depth survey on phone tower footing
3D survey evidence of a disputed dowel bar that had been correctly placed
Roy Gripske & Son, Melbourne.
Analysis of precast Super “T’s” and
topping slab design
CAD mark-up of a GPR survey at Flinders University
Bridge survey on 100 year old bridge
Void detection using MIRA ultrasound equipment on a rail bridge at Seaford, SA
Tank roof surveys around Hobart
for Waternish Constructions
on behalf of TasWater
10,000 sq. metre pavement defect survey using multiple frequency antennae sled
Angle Vale heritage listed timber bridge. UPV & GPR survey for defect testing
Looking for unknown services before excavating at Nystar smelter, Port Pirie using GPR
All images are off surveys taken by Soft Scan
All images remain the property of Soft Scan
